2.74 m
Scale anchored to a reviewed measurement
Uniformly scaled by complete plan-view length.
New Horizons, Deployed
New Horizons is NASA's active outer-solar-system probe, the first spacecraft to explore Pluto close up and later the Kuiper Belt object Arrokoth. It is represented in complete flight configuration with its thick triangular bus, 2.1 m high-gain dish, side-mounted radioisotope generator, and science instruments. The documented envelope is about 2.74 × 2.11 × 0.68 m and the spacecraft mass is 478 kg.
Dimensions
- Height
- 68 cm
- Length
- 2.74 m
- Width
- 2.11 m
- Weight
- 478 kg
Quick facts
- Length
- 2.74 m
- Width
- 2.11 m
- Antenna diameter
- 2.1 m
- Mass
- 478 kg
- Launch
- 19 January 2006
New Horizons, Deployed · Size infographic
Related objects
Sources and measurement44 References
Dimensions were cross-checked against independent sources before publication.
Measurement basis
The top view uses the documented 2.74 by 2.11 m plan envelope; the dish diameter is a visual cross-check.
