M1A2 SEPv3 Abrams (Current)

The current-production M1A2 SEPv3 Abrams is represented in the U.S. Army's complete combat configuration, with its turret at twelve o'clock and 120 mm gun level and forward. The documented outer envelope is 9.855 m long, 3.658 m wide and 3.404 m high, with a listed mass of about 66.8 tonnes.

Dimensions

Height
3.4 m
Length
9.86 m
Width
3.66 m
Weight
66.76 t

Quick facts

Combat-config length
9.855 m
Width
3.658 m
Height
3.404 m
Mass
about 66.8 t
