Falcon 9 Block 5 with Standard Fairing

Scale anchored to a reviewed measurement

Uniform scaling uses one documented measurement; the visual contour is never deformed to fit a second axis.

Falcon 9 Block 5 with Standard Fairing

The complete Falcon 9 Block 5 is shown in standard payload-fairing launch configuration from a strict orthographic front elevation. The documented 70 m height is the scale anchor; the 3.7 m body diameter and 549,054 kg launch mass remain sourced physical dimensions.

Dimensions

Height: 70 m
Length: 3.7 m
Width: 3.7 m
Weight: 549.05 t

Quick facts

Height: 70 m
Diameter: 3.7 m
Launch mass: 549,054 kg
First stage: 9 Merlin engines

Falcon 9 Block 5 with Standard Fairing · Size infographic

Falcon 9 Block 5 with Standard Fairing: Size infographic · Height 70 m · Length 3.7 m · Width 3.7 m
